Auger Powder Filler Machine Auger Powder Filler Machine
Auger Powder Filler Machine
Auger Powder Filler Machine

Auger Powder Filler Machine

2.00 - 15.00 INR

Product Details:

X

Auger Powder Filler Machine Price And Quantity

  • 1 Piece
  • 2.00 - 15.00 INR

Auger Powder Filler Machine Trade Information

  • Letter of Credit (L/C) Letter of Credit at Sight (Sight L/C) Cash Against Delivery (CAD) Telegraphic Transfer (T/T) Cash in Advance (CID) Cheque Cash Advance (CA)
  • 30 Piece Per Month
  • 8 Week
  • Yes
  • Contact us for information regarding our sample policy
  • Wooden Packing Only
  • Australia North America South America Eastern Europe Middle East Central America Africa Western Europe Asia
  • All India
  • CE & ISO Certified

Product Description

Auger Powder Filler Machine

Automatic Auger Type Dry Syrup Powder Filling Machine is a compact model used for filling Dry Syrup Powder in bottles.

The incoming dry bottle sterilized is fed through the in feed Turn Table with suitably guided on the moving delrin flat conveyor belt at the required speed for feeding. There are two separate filling head mounted on machine top plate in the same line. When bottle reaches to the first filling station, it will be held by the pneumatic bottle holder. Immediately it will be sensed by the bottle sensor as soon as it gets signals from sensor magnetic clutch starts to rotate which is mounted on auger shaft. It will fill the desired amount of powder to the bottle through auger, where rotation time is previously saved in PLC control. After filling of first bottle pneumatic piston goes back and release the first bottle to move on conveyor, By the same time second bottle also moves along with the first bottle in empty condition. In second filling head same operation will be performed but this time second bottle get filled and first bottle moves further for next operation. The main advantage of this machine is Pneumatic bottle holding system is directly connected with Auger rotation, so till bottle get filled with powder as per set value pneumatic system will not going to release the bottle.


Salient Features :



  • Total Compact c GMP model.
  • All parts and assemblies coming in contact with powder and rubber stopper are made of S.S.316 and easily removable for mandatory Autoclaving / Sterilization.
  • "NO BOTTLE, NO FILL" System eliminates wastage of costly powder.
  • Conveyor driving is through High quality imported Gear motor
  • Machine speed can be adjusted by A.C. Frequency drive, which is time saving.
  • Machine is provided with delrin conveyor belt to avoid sticking of vial on conveyor.
  • Single track bottle movement, reduces setting of supporting guide rails and semi skilled person can also easily operate the machine.
  • Pneumatic bottle holding system is connected with auger rotation, which eliminates chances of bottle transfer before completion of filling operation.
  • No change parts are required for any change in bottle diameter from 30 to 120 ml.
  • Imported Gear Motor for Conveyor drive.
  • A.C. Frequency drive for Conveyor drive.
  • "No Bottle, No Filling" System.
  • Pneumatic bottle holding system.


Technical Specifications :

Model SBAF-60 SBAF-D-100
Direction Left To Right. Left To Right.
Production Rate Up to 30 to 40 Bottles / Min Up to 60 to 80 Bottles / Min.
Fill Capacity 10 grms to 50 grms. (with different set of Auger and funnel) Fill range depending upon Bottle opening and bulk density of powder. 10 grms to 50 grms. (with different set of Auger and funnel) Fill range depending upon Bottle opening and bulk density of powder.
Accuracy ± 2% depending upon consistency and the Uniformity of bulk density of powder under controlled level of Humidity (i.e.35%) ± 2% depending upon consistency and the Uniformity of bulk density of powder under controlled level of Humidity (i.e.35%)
No. of Heads Single Two
Electrical Supply 1.00 HP For Main Drive.
0.25 HP for conveyor
2.00 HP For Main Drive.
0.25 HP for conveyor
Power Requirement 440 Volts, 3 Phase (4 wire System) 50 Hz. 440 Volts, 3 Phase (4 wire System) 50 Hz.
Height of Conveyor Adjustable from 850 To 900 mm Adjustable from 850 To 900 mm
Dimensions 1524 mm (L) X 1105 mm(W) X 1800 mm (H) 2200 mm (L) X 1102 mm (W) X 1817 mm (H)
Net Weight 400 KGS. (Approx.) 550 KGS. (Approx.)
Gross Weight 600 KGS. (Approx.) 800 KGS. (Approx.)
Bottle Diameter 25 mmTo 70 mm MAX. 25 mm To 70 mm MAX.
Height 55 mm To 110 mm. 55 mm To 110 mm.
Pneumatic Air Filtered, oil free, sterile low pressure AIR at 5 kg / cm2 Filtered, oil free, sterile low pressure AIR at 6 kg / cm2
