Fluid Bed Processor - (With Top Spray Facility only).

Fluid Bed Processor - (With Top Spray Facility only).
Send Inquiry
Product Code : GMP Model
Brand Name : Shree Bhagwati
Price And Quantity
  • Minimum Order Quantity
  • 1 Piece
  • Price
  • 5 to 25 INR
Product Specifications
  • Type
  • Pharmaceutical Packaging Machine
  • Material
  • stainless steel
  • Capacity
  • As per the client required Kg/hr
  • Computerized
  • Yes
  • Control Mode
  • Automatic
  • Voltage
  • As per the client required Watt (w)
  • Power
  • As per the client required Watt (w)
  • Weight (kg)
  • In kgs Kilograms (kg)
  • Dimension(L*W*H)
  • In inches Inch (in)
  • Color
  • stainless steel
  • Warranty
  • 1 year
Product Description
Features
  • Washing port on top dish for WIP. ( Spray ball and CIP system will be in  customer scope )
  • Silicon inflatable gasket at top & bottom of the container  & at bag sealing.
  • Trolley of container with PU wheel.
  • Atmospheric inlet air is filtered by means of 05, 03& 0.3 microns filters.
  • Temperature sensors for inlet & out let air temperature.
  • Cooling coil with Rh sensor for humidity control atinlet air  AHU.
  • Inlet air temperature controlling & outlet air temperature indicating.
  • PUF  insulated  double skin  AHU  with inside galvanize sheeting up to the
  • Hepa filter with Pre ( 05 micron ) & Micro V ( 03 micron )filters in aluminum box. SS304 sheeting from Hepa filter to air outlet &Hepa Filters also in SS304 box. Outside powder coated galvanized. Cooling coilmade out of copper tube & aluminum fins. Steam coil made out of SS tube& aluminum fins.
  • An explosion safety flap of adequate capacity at the rear of expansion chamber.
  • An earthing point will be provided in the machine.
  • Contact parts will be polish to the mirror finished and other parts are polish to the mat finished in GMP Model.
  • Blower made out of mild steel and painted.
  • All light glass & sight glass with T/C ended connection.
  • Inlet air ducting made out of SS304.
  • Butter fly valve with pneumatic On-Off type actuator at inlet and outlet air duct.
  • Out let air ducting made out of SS304.
  • Facility for providing filter / heaters chamber and blower/motor outside the production room.
  • Container sieve supported with perforated sieve.
  • PLC & Color  Touch screen for automation.
  • VFD with velocity sensor for CFM control and CFM display.
  • 01 no. of extra product container.
  • Top spray facility for wet granulation. ( This system includes solution vessel,
  • peristaltic pump, silicon tubing, spray nozzle ( anyone size ) with mounting facility and complete system can be control from PLC /TOUCHSCREEN.
  • Contact parts made out of SS316 & non contact parts made out of SS304 OR
  • heavy parts made out of mild steel and claded or covered with SS304.
TECHNICAL SPECIFICATIONS :

Working capacity of dryer in kgs. at 0.6gms/cc bulk density.

80 to 120

Working capacity of product container in liters.

200

Total volume of product container in liters

415

Blower motor HP.

25

Steam consumption at 4 kgs. pressure ( If steam heated )

200 Kgs.

Air consumption at 4 kgs. Pressure

6 cfm





Trade Information
  • FOB Port
  • India
  • Payment Terms
  • Telegraphic Transfer (T/T), Letter of Credit (L/C), Delivery Point (DP), Cheque, Cash in Advance (CID), Cash Advance (CA), Cash on Delivery (COD)
  • Supply Ability
  • 30 Piece Per Week
  • Delivery Time
  • 8-10 Week
  • Sample Available
  • Yes
  • Sample Policy
  • Contact us for information regarding our sample policy
  • Packaging Details
  • Wooden Packing only
  • Main Export Market(s)
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • Main Domestic Market
  • All India
  • Certifications
  • ISO and CE Certified
