AUTOMATIC SIX HEAD LIQUID FILLING MACHINE

Send Inquiry

Request To Call Back

AUTOMATIC SIX HEAD LIQUID FILLING MACHINE

Price 650000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

AUTOMATIC SIX HEAD LIQUID FILLING MACHINE Specification

Type
Filling Machine

Material
Stealness Steel

Auxiliary Packaging Machine Type
Other

Capacity
10 ml to 1000 ml Kg/hr

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Control

Drive Type
Electric

Voltage
Watt (w)

Warranty
1 year

AUTOMATIC SIX HEAD LIQUID FILLING MACHINE Trade Information

Minimum Order Quantity
1 Unit

FOB Port
India

Payment Terms
Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Cash Against Delivery (CAD), Telegraphic Transfer (T/T), Days after Acceptance (DA), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
30 Units Per Week

Delivery Time
4 Week

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Wooden packing Only

Main Export Market(s)
South America, Western Europe, Middle East, Central America, Asia, Eastern Europe, North America, Australia

Main Domestic Market
All India

Certifications
ISO and CE Certified

About AUTOMATIC SIX HEAD LIQUID FILLING MACHINE

Operation

Nozzle goes upwards slowly from the bottom level of bottle towards neck during filling to minimize forming adjustable nozzle is reciprocating according to filling dose. The dosing block with a hexagonal bolt, this means different fill size can be set easily within minimum of time. The main drive consists of a helical gearbox driven by A/c motor & through controlled by an Ac frequency drive. The speed can be set in terms of bottles per minute. The conveyor drive consists of a hallow shaft, geared motor controlled by an AC frequency drive. A knob can set the speed of conveyor.

Technical Specification

Model No.		SBLF 200 GMP Model
Output/Min		Up to 40-50 BPM (Depends upon Fill size)
Direction of Movement		Left to Right
Number of head/syringe		6 Nos.
Fill Size		100 ml to 1000 ml (With help of change parts)
Electrical Specification	Main Machine	2.0 HP / 415 Volts / 50 Hz.
	Conveyor	0.5 HP / 415 Volts / 50 Hz.
Height of Conveyor		860 mm to 910 mm adjustable.
Change parts required		(A) Syringes. / (B) Nozzle / (C) Inlet & outlet hose pipe

Dependson size, shape and Neck dia of container, Fill volume and nature of Liquid etc.

Can be supplied as percustomer requirements.

With help of change parts.

Salient Features

The unit is made compact & versatile

S.S. Slat conveyor.

S.S. Elegantly Matt Finished Body

No Container No filling system.

Reciprocating Filling nozzle with self centering device

Pneumatically operated bottle stopper

Advanced Filling Performance

Equipped with six filling heads, this automatic machine maximizes throughput and consistency for liquid packaging. The computerized PLC control system allows for customized settings, ensuring optimal accuracy for different volumes, from small 10 ml vials up to 1000 ml containers. Stainless steel construction meets industry hygiene requirements, ideal for food, pharmaceutical, or chemical production.

User-Friendly Operation

Designed with an intuitive interface, the machine makes changing settings and monitoring operations straightforward. Its electric drive and PLC automation minimize manual intervention, reducing downtime and boosting overall productivity. Users benefit from simplified maintenance and safe, ergonomic design.

FAQs of AUTOMATIC SIX HEAD LIQUID FILLING MACHINE:

Q: How does the Automatic Six Head Liquid Filling Machine work?

A: The machine operates using six simultaneous filling heads that dispense measured liquid quantities into containers. The PLC control system manages filling speed and volume, while the electric drive ensures steady and reliable performance during operation.

Q: What types of liquids can be filled with this machine?

A: The machine is designed to handle a variety of liquid products such as beverages, pharmaceuticals, chemicals, oils, and cosmetic solutions within the 10 ml to 1000 ml range, making it versatile for several industries.

Q: When should manufacturers consider using this automatic filling machine?

A: Manufacturers requiring precise, high-speed bulk filling for medium to large scale production should utilize this machine, especially when consistent product accuracy and minimal manual intervention are necessary.

Q: Where is the Automatic Six Head Liquid Filling Machine available for purchase?

A: This machine is available from distributors, exporters, manufacturers, and suppliers throughout India. Interested buyers can contact local authorized vendors for procurement and support.

Q: What benefits does the computerized PLC control offer to users?

A: The advanced PLC control system provides accurate volume adjustments, simple programming, and seamless integration with other automated processes, improving operational efficiency and reducing the risk of human errors.

Q: How is the installation and usage process managed?

A: Installation is typically supported by the supplier, who provides setup and training. Usage involves loading containers, selecting desired settings on the PLC panel, and initiating the automatic filling cycle, which requires minimal supervision.

Q: What warranty and after-sales service can customers expect?

A: Customers receive a one-year warranty covering manufacturing defects. Most suppliers in India offer prompt after-sales support, ensuring maintenance and addressing technical issues to maintain optimal machine performance.
