D4 Type Square GMP Model D4 Type Square GMP Model D4 Type Square GMP Model D4 Type Square GMP Model D4 Type Square GMP Model
D4 Type Square GMP Model
D4 Type Square GMP Model D4 Type Square GMP Model D4 Type Square GMP Model D4 Type Square GMP Model

D4 Type Square GMP Model

3.00 - 15.00 INR

Product Details:

X

D4 Type Square GMP Model Price And Quantity

  • 3.00 - 15.00 INR
  • 1 Piece

D4 Type Square GMP Model Trade Information

  • Cash Against Delivery (CAD) Cash Advance (CA) Letter of Credit (L/C) Letter of Credit at Sight (Sight L/C) Telegraphic Transfer (T/T) Cash in Advance (CID) Cheque
  • 30 Piece Per Month
  • 8 Week
  • Yes
  • Contact us for information regarding our sample policy
  • Wooden Packing Only
  • Australia South America Middle East Africa Western Europe Central America Asia Eastern Europe North America
  • All India
  • CE & ISO Certified

Product Description

Manufacturer and supplier of square GMP model single rotary tablet press machine with hygienic features.  D4 Type Square GMP Model is also called as double rotary tablet press machine and is commonly used for slugging big tablets.  We specialize in designing 8 station rotary tabletting machine,  10 station rotary tabletting machine, 12 station rotary tabletting machine, 16 station rotary tabletting machine, 27 station rotary tabletting machine and 35 station rotary tabletting machines according to the requirement of various pharmaceutical and chemical industries.

Salient Features :
  • Square GMP Model
  • Machine is having C.I. Body & C.I. middle plate
  • Easy and More thorough Cleaning
  • Paint free tablet manufacturing zone.
  • Excellent and Operator Friendly Material Feeding System
  • Lower Guards of Polished Stainless Steel
  • Upper Guards of transparent Acrylic material
  • Electronic / Digital, Tablet Cum RPM Counter
  • Turret of Special Grade S G IRON casting
  • Lower Punch wiper Seal to prevent lower Punch jamming
  • Aluminium turret speed 17 to 42 RPM
  • Phosphorous bronze bush provided inside the turret hole
  • Imported needle roller bearing provided at the bottom of turret
  • Cam tracks & pressure rolls made out alloy steel
  • Worm is made of Phosphorous bronze material
  • Separate grinded center pillar of M.S. Material
  • Upper punch penetration system
  • Effective Dust Extraction Nozzles
  • Inter Lock Swutcges to all Guards
  • Variable Speed Pulley
  • One Shot Lubrication System
  • Double Sided Lifting Cams
  • Anti Vibration ounts
  • Overload Pressure Release System
  • Reverse direction motion protection is provide to avoid major accident

Available with AC Variable Drive & Electromagnetic Clutch (Optionally)
Available with force feeding attachment (Optionally)
Pre. Compression Arrangement (Optionally)
Nation Wide after Sales Service Network

Technical Specification :
D4 Type
Machine Type Bhagwati-D4-16D Bhagwati-D4-20D Bhagwati-D4-23 DB
Number of Stations 16 20 23
Type of Tooling Punch D D DB
Output - Tablets / Hr. 13,440 - 40,320 16,800 - 50,400 19,320 - 57,950
Max. Operating 10 Tons 10 Tons 10 Tons
Max. Tablet Dia 25 mm 25 mm 16 mm
Max. Depth of fill 20.5 mm 20.5 mm 17.5 mm
Upper Punch Penetration 1.5 - 8 mm 1.5 - 8 mm 1.5 - 8 mm
Main Electric Motor 3 HP/ 2.2 kW
1440 RPM, 415 V.,
3 Phase, 50 Hz.
3 HP/ 2.2 kW
1440 RPM, 415 V.,
3 Phase, 50 Hz.
3 HP/ 2.2 kW
1440 RPM, 415 V.,
3 Phase, 50 Hz.
Overall Dimension (cm) 98 x 102 x 182 H 98 x 102 x 182 H 98 x 102 x 182 H
Net Weight (Kgs) 1150 1150 1150

Technical Specification :
Slugging Type [For veterinary Tablets]
Machine Type   D4-8-SLG D4-12-SLG
Number of Stations   8 12
Output - Tablets /Hr. 12 RPM
22 RPM
5,760
10,560
8,640
15,840
Max. Operating   12 Tons 12 Tons
Max. Tablet Dia   40 mm 40 mm
Max. Depth of fill   30.0 mm 30.0 mm
Upper Punch Penetration   1.5 - 8 mm 1.5 - 8 mm
Main Electric Motor   5 HP/ 930 RPM
3 Phase, 440 V
5 HP/ 930 RPM
3 Phase, 440 V
Overall Dimension (cm)   98 x 102 x 182 H 98 x 102 x 182 H
Net Weight (Kgs)   1250 1250

Note : Specification and features of the machineries are subject to change without any prior notice
