Rotary Sticker Labelling Machine for Square Bottle:

Name: Rotary Sticker Labelling Machine for Square Bottle:
Brand: SHREE BHAGWATI MACHTECH (I) PVT. LTD.
Price: 900000 INR
Availability: InStock

Price 900000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Rotary Sticker Labelling Machine for Square Bottle: Specification

Product Type
Rotary Sticker Labelling Machine for Square Bottle

Material
Stainless Steel with Powder Coated Frame

Application
Labeling Square Bottles (Glass, PET, HDPE, etc.)

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Based

Drive Type
Electric Servo Motor

Accuracy
1 mm

Power Source
Electric

Voltage
220V / 380V, 50/60Hz

Weight (kg)
Approx. 650 kg

Dimension (L*W*H)
2200 mm x 1500 mm x 1750 mm

Capacity
Up to 120 Bottles per Minute

Feature
No Bottle - No Label, Self-adhesive Labelling, Transparent Label Sensor, Variable Speed Drive

Color
Grey & Silver

Conveyor Belt Width
90 mm (Adjustable)

Fault Indication
Error Display on Screen

HMI Display
Touchscreen

Change Over Time
Less than 15 Minutes

Operating Environment
5C to 45C, up to 90% RH non-condensing

Labelling Speed
Variable, Programmable

Label Size Range
Height: 8 mm to 90 mm, Length: 12 mm to 200 mm

Label Roll Diameter
Inner: 75 mm / Outer: Up to 300 mm

Noise Level
75 dB

Bottle Size Range
Height: 50 mm to 300 mm, Width: 25 mm to 100 mm

Safety Features
Emergency Stop Switch and Safety Guards

Labelling Type
Wrap Round and Partial Wrap-Around

About Rotary Sticker Labelling Machine for Square Bottle:

Discover the latest Rotary Sticker Labelling Machine for Square Bottles-a noble addition to any industrial setup seeking exceptional efficiency and accuracy. With access to advanced programmable features and a modern touchscreen HMI, this laureate of labelling solutions accommodates various bottle sizes and label dimensions with ease. Engineered with stainless steel and a powder-coated frame, its computerized, PLC-based automatic control system ensures precise labelling-up to 1 mm accuracy-on glass, PET, and HDPE bottles. Benefit from noble safety features, variable speed drive, error indication display, and transparent label sensors for seamless and reliable operations.

Highlighted Features and Application Surfaces

This Rotary Sticker Labelling Machine offers a multitude of features including no bottle-no label detection, self-adhesive labelling, emergency stop switch, and safety guards for exceptional operator protection. The wrap-round and partial wrap-around labelling options cater to a wide label size range, with remarkable change over time of under 15 minutes. Its adjustable conveyor belt efficiently accommodates square bottles of different surfaces-glass, PET, HDPE, and more-ensuring consistent, high-quality results every cycle.

Sample Access, Certifications, and Transportation

Secure shipping and timely delivery are guaranteed for all Rotary Sticker Labelling Machine orders. Sample units are available upon request, ensuring you access the product prior to bulk purchase. With FOB port facilities and a competitive rate, our transportation process is efficient and reliable. The machine comes certified, assuring compliance and exceptional performance as a trusted distributor, exporter, manufacturer, and supplier across India and global markets.

FAQ's of Rotary Sticker Labelling Machine for Square Bottle::

Q: How does the Rotary Sticker Labelling Machine ensure accurate label placement on square bottles?

A: The machine is engineered with an electric servo motor and programmable PLC controls, providing exceptional labelling accuracy up to 1 mm. Transparent label sensors and a modern touchscreen HMI enable precise adjustment, ensuring consistent label placement on every bottle.

Q: What is the process for changing label sizes or bottle formats with this machine?

A: Changeover is remarkably efficient; the machine is designed to switch between label or bottle formats in less than 15 minutes, aided by adjustable conveyors and programmable memory settings that streamline setup and reduce downtime.

Q: When should the fault indication feature be used, and how does it help?

A: The error display on the touchscreen HMI automatically activates when it detects any operational faults or misalignments. This feature allows operators to promptly address issues, minimizing disruptions and maintaining workflow continuity.

Q: Where can this labelling machine be installed, and what are the environmental requirements?

A: It can be installed in a wide range of industrial environments; the machine operates optimally between 5C to 45C with up to 90% RH (non-condensing humidity), and it meets the electrical requirements of 220V / 380V, 50/60Hz power supply.

Q: What are the primary benefits of using this automatic labelling machine for square bottles?

A: Users gain access to increased productivity, consistent label quality, robust safety features, and reduced manual intervention. The noble combination of high speed (up to 120 bottles per minute) and the capability to handle bottles of various materials makes it a laureate choice for manufacturers, distributors, and exporters.
