Volumetric Liquid Bottle Filling

Automatic Bottle Filling Machine for Shampoo, Lotion ,Gel ,Hair oil ,Perfume ,Beverages ,Juice ,Wine ,Liquid Soap ,Lubricant oil ,Engine oil ,Cleaning chemical Hazardous liquid ,Acid etc.work on volumetric principle with diving nozzles. The unit is made compact, versatile and enclosed in stainless steel elegantly matt finish body, of S.S Slat Conveyor, Reciprocating Nozzle with self-cantering devices & SS Syringe. No container the main drive of the machine and conveyor drive consist of A/C Motor with synchronized variable A/c Frequency drive. Operation : Containers moving on S.S. Slat conveyor, feed below the filling nozzles through a settable twin pneumatically operated stopper system. The twin pneumatically operated stopper system and reciprocating nozzles can precisely match for cantering of container below nozzles, to avoid spillage of liquid on container. To minimize foaming adjustable nozzle will reciprocate according to filling dose, nozzle will go upwards slowly from bottom level of bottle towards neck during filling. The dosing block with a hexagonal bolt fitted below syringes. This means fill size can be easily set. Salient Features : Geneva mechanism. ± 1% Filling accuracy on single dose. No bottle No filling system. Rigid vibration free construction for trouble free performance. S.S. Elegantly matt finished body. Elegant and easy control panel for total control on operation. Minimum change overtime, from one size to another container or fill size. Self lubricating UHMW-PE guide profile for SS slat chain provides low friction wear surface, smooth and noiseless conveying. Drip tray under the conveyor. Pneumatic bottle stopping arrangement. Safety guard for conveyor gear box, motor and pneumatic cylinders. MCB for over load protection, and prevention against short circuit. Nitrogen flushing system provided (Pre or Post) as required by customer. Optional Features : Geneva mechanism. Automatic chain washing system for conveyor belt. In-built pre-inspection. Acrylic cabinet. Acrylic cover on conveyor. Nitrogen Flushing. Float tank (Holding tank) with or without stirrer. Utility Requirement : Electrical Supply: Three Phase + Neutral + Earthing Electrical Load: 2 KW Air Pressure: 6 bar pressure 0.5 CFM Technical Details: Model SBVF - 150 Output/Hour 3600 to 9000* Direction of Movement Left to Right Number of head/syringe 6 Nos. Fill Size 5 ml to 1000 ml Electrical SpecificationMain Machine 1 HP /415 Volts / 50 Hz. (2 HP if maximum volume is 1000 ml in single doze) 0.5 HP / 415 Volts / 50 Hz. Height of Conveyor 860 mm to 910 mm adjustable. Change parts required (A) Syringes. (B) Nozzle (C) Inlet & outlet hose pipe

* Depends on size, shape and Neck Dia of container, Fill volume and nature of liquid etc. Can be supplied as per customer requirements. With help of change parts. * Note : With the help of the change parts.

Precision Filling Across a Wide Range

This machine can accurately fill bottles with liquid volumes from 5ml up to 1000ml. Its high-precision volumetric technology ensures every bottle is dispensed the exact amount, reducing wastage and ensuring quality consistency. The systems adaptability makes it suitable for various liquid products, including pharmaceuticals, food, and chemical solutions.


Advanced Stainless Steel Construction

Built entirely from stainless steel, the machine is both corrosion-resistant and easy to clean. This ensures product safety and longevity even in demanding industrial environments. Stainless steel construction also meets stringent international hygiene standards, making this filler ideal for sensitive applications.


User-Friendly Automation and Customization

With an automatic grade and intuitive Human Machine Interface, this bottle filling machine is simple to operate. The voltage can be tailored to client requirements, and the systems control optionsranging from frequency speed control to computerized operationoffer flexible integration into any production line.
