Top and Bottom Sticker Labelling Machine

Price 750000 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Top and Bottom Sticker Labelling Machine Specification

Product Type
Top and Bottom Sticker Labelling Machine

Material
Stainless Steel, Mild Steel

Application
Labeling on Top and Bottom of Flat/Oval/Square/Tray Bottles, Containers, Boxes, Pouches, etc.

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Control System

Drive Type
Electric

Accuracy
1 mm

Power Source
Electric

Voltage
220-240V AC, 50/60 Hz

Weight (kg)
Approx. 350 kg

Dimension (L*W*H)
2000 mm x 1000 mm x 1500 mm

Capacity
Up to 120 products/minute (Depending on product and label size)

Feature
Dual Head Labeling, Fast Changeover, User-Friendly Touch Screen HMI, Synchronized Speed Control

Color
Silver, Blue & Grey

About Top and Bottom Sticker Labelling Machine

Automatic HorizontalSticker Labelling Machine Model SBHSL 150. Is one of the most users friendly. The Machine incorporates latest sophisticated Micro Processor Control LabelDispensing system with user friendly Sensing system for Label and Product.Machine suitable for Aluminium, Glass, Plastic, Cartons , Batteries, Pouches etc.

Precision Labeling for Diverse Products

This machine delivers accurate sticker placement on a wide variety of containers including bottles, trays, pouches, and boxes. Its dual head design enables synchronous top and bottom labeling, catering to flat, oval, and square products with absolute precision and flexibility.

Effortless Operation and Job Management

Operate the machine smoothly with its user-friendly touchscreen HMI, which allows for variable speed adjustment and programmable memory storage for multiple labelling jobs. Fast changeover ensures minimal downtime between production batches, enhancing overall efficiency.

Reliable Performance and Safety Assurance

Constructed from stainless steel and mild steel, the machine features a noise level below 75 dB and comprehensive safety mechanisms such as an emergency stop, overload protection, and safety interlock. Optical fiber sensors guarantee precise label and product detection throughout operation.

FAQs of Top and Bottom Sticker Labelling Machine:

Q: How does the Top and Bottom Sticker Labelling Machine ensure accurate label placement?

A: The machine is equipped with optical fiber sensors for both label and product detection, which, combined with PLC control and synchronized speed adjustment, deliver labeling accuracy within 1 mm for consistent and precise performance.

Q: What types of products can I label using this machine?

A: It is designed to label the top and bottom surfaces of a variety of products such as flat, oval, and square bottles, containers, boxes, trays, and pouches, making it suitable for diverse packaging requirements.

Q: Where can the machine be installed for optimal functioning?

A: For best results, install the machine in an environment with temperatures between 5C to 45C and relative humidity up to 90% (non-condensing), ensuring proper electrical connections at 220-240V AC, 50/60 Hz.

Q: What is the process for changing label size or product type on this machine?

A: Changing label sizes or product types is straightforward due to the machines fast changeover capability and programmable memory. Operators can adjust label length, width, and conveyor settings via the touchscreen HMI and select stored job parameters for different batches.

Q: When should the emergency stop or safety features be used?

A: Safety features like the emergency stop, overload protection, and safety interlock should be activated during any operational anomaly, product jams, or maintenance to prevent accidents and safeguard both operators and equipment.

Q: What are the benefits of using this dual head labeling machine?

A: Benefits include high labeling speed (up to 120 products per minute), dual head for top and bottom application, user-friendly controls, fast changeover between jobs, reliable accuracy, and robust stainless steel construction for long-term use in modern production environments.
