Stainless Steel Carbonated Beverage Bottling Equipment 15000 BPH Energy Saving

Send Inquiry

Request To Call Back

Stainless Steel Carbonated Beverage Bottling Equipment 15000 BPH Energy Saving

Get a Price/Quote

MOQ : 1 Piece

Stainless Steel Carbonated Beverage Bottling Equipment 15000 BPH Energy Saving Specification

Type
Packaging Line

Material
Stainless steel

Feature
Beverage, Food

Auxiliary Packaging Machine Type
Other

Capacity
As per the client required Kg/hr

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Control

Drive Type
Electric

Power
As per the client required Watt (w)

Voltage
As per the client required Watt (w)

Weight (kg)
In Kgs Kilograms (kg)

Dimension (L*W*H)
In inches Inch (in)

Color
Other

Warranty
1 year

Stainless Steel Carbonated Beverage Bottling Equipment 15000 BPH Energy Saving Trade Information

Minimum Order Quantity
1 Piece

FOB Port
India

Payment Terms
Days after Acceptance (DA), Delivery Point (DP), Letter of Credit (L/C), Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque

Supply Ability
30 Pieces Per Week

Delivery Time
12 to 14 Week

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Wooden box packing

Main Domestic Market
All India

Certifications
ISO and CE Certified

About Stainless Steel Carbonated Beverage Bottling Equipment 15000 BPH Energy Saving

Feature of Carbonated soft drink filling machine:

1. adopts the negative pressure filling which we specifically design for CSD filling, it ensures minimal loss of CO2 from the product
2. The configuration of filler is advanced, pithy and rational and the driving and up-down transmission is located between the stainless steel working plat and the bracket and their waterproof is good, sanitary and credible and adjusting and maintaining are very easy.
3. We design the filling valves on basis of foreign advanced technique for adapting high-speed hot filling. It can ensure the valves open and close flexibly because of using guide sheath. Adopting easy-fixed configuration, the valve is easy to cleaning promptly and has automatic cleaning function.
4. The filling operation is faster and more stable because the new type micro pressure filling system is adopted.
5. The electro pneumatic filling valves are equipped with interchangeable level tubes to make the best precision filling, and the filling level for the bottle is adjust.

Water Treatment System for Carbonated drink filling lines:

The reverse osmosis device is an equipment to purify the saltine water with the action of pressure difference of semi permeable membrane. It adopt the larger osmotic pressures used to obtain the purpose to separate, extract, purify and condense.

Technical Parameter:

Item	SB16--16-5	SB18-18-6	SB24-24-8	SB32-32-10
Capacity	4000bph(500ml)	5000bph(500ml)	8000bph(500ml)	15000bph(500ml)
Rising heads	16	18	24	32
Filling heads	16	18	24	2
Capping heads	5	6	8	10
Bottle Diameter	Commonly 50-110mm (can adjustable)
Bottle Height	Commonly 150-340mm(can adjustable)
Filling pressure	0.15-0.35Mpa
Rising pressure	0.2-0.25Mpa
Overall size	213017002350	245018002350	278022002350	360026502350
Weight	3.3t	3.5t	4.5t	5.5t

Advanced Technology for Efficient Bottling

Equipped with state-of-the-art PLC control and fully computerized automation, this bottling line streamlines production for carbonated beverages. The robust stainless steel build ensures durability and compliance with hygiene standards, making it suitable for both beverage and food industries.

Tailored Solutions for Your Facility

With customizable voltage, power, and capacity options, the equipment adapts to specific client needs. Its automatic grade and electric drive type enhance productivity while saving energy, offering a reliable packaging solution for large-scale beverage manufacturers.

FAQs of Stainless Steel Carbonated Beverage Bottling Equipment 15000 BPH Energy Saving:

Q: How does the PLC control system improve the bottling process?

A: The integrated PLC control system automates and monitors each stage of the bottling process, ensuring accuracy, consistency, and efficient management of operations. This reduces manual intervention, helps minimize errors, and increases throughput for carbonated beverage packaging.

Q: What customization options are available for power, capacity, and voltage?

A: Clients can specify their required power and voltage, as well as the desired capacity per hour, allowing the equipment to be tailored to different operational scales and geographical requirements. This ensures optimal utility across various bottling environments.

Q: When should routine maintenance be scheduled for this equipment?

A: Routine maintenance is recommended at regular intervals as advised in the product manual, typically every few months or after a specified number of operational hours. Adhering to maintenance schedules ensures longevity, energy efficiency, and consistent performance.

Q: Where can this bottling line be installed?

A: This automatic packaging line is designed for flexible installation in beverage production facilities, food processing plants, and manufacturing units. Its dimensions and features can fit into diverse industrial settings across India, suitable for both new and upgraded lines.

Q: What are the benefits of using stainless steel material in the equipment?

A: Stainless steel offers superior resistance to corrosion, maintains sanitary processing conditions, and is easy to clean, which is vital in the beverage and food industries. It ensures product purity and extends the lifespan of the packaging equipment.

Q: How does this equipment help save energy during operation?

A: The equipments electric drive and advanced automation technologies reduce unnecessary power consumption by optimizing the bottling process. This results in lower energy costs and a more sustainable operation for manufacturers.

Q: What is included under the one-year warranty for this machinery?

A: The one-year warranty covers manufacturing defects, malfunctions originating from standard use, and technical support for repairs and spare parts. It offers clients reassurance and minimizes downtime by addressing operational issues promptly.
