Screw Cap Sealing Machine -Screw capper

Price 375000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Screw Cap Sealing Machine -Screw capper Specification

Product Type
Screw Cap Sealing Machine

General Use
Industrial

Computerized
No

Automatic
Yes

Control System
Human Machine Interface

Voltage
110-215 Volt (v)

Feature
ECO Friendly

Color
Silver

Screw Cap Sealing Machine -Screw capper Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash Against Delivery (CAD), Letter of Credit (L/C), Telegraphic Transfer (T/T), Letter of Credit at Sight (Sight L/C), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
30 Units Per Month

Delivery Time
4-6 Week

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Wooden Packing Only

Main Domestic Market
All India

Certifications
CE & ISO Certified

About Screw Cap Sealing Machine -Screw capper

Screw Cap Plastic Cap Sealing Machine

Description:

BHAGWATIs Automatic Screw Capping Machine is versatile, self-supported on stainless steel leg with height adjustable adjustment system. The machine is precision built on sturdy welded steel frame completely enclose in stainless steel sheet and doors are providing to facilitate the servicing of machine.

Operation :

The feed container moving on conveyor belt are feed into an in-feed star wheel, bringing the container below the sealing head in the subsequent indexing part, mean while the rotating head pickup a cap from the cap star wheel which is receiving from delivery chute of cap filling bowl, where the body and the neck of the container are positioned below the rotating head, where the sealing head is performing perfect operation of sealing, rotating head is design to seal container according to pre-set torque.

Technical Specification :

Model		SBCS-50
Output / Hour*		1000 to 3000 bottles.
Direction of Movement		Left to Right
No. of Sealing Head		1 Nos.
Electrical Specification	Main Motor	1.0 HP / 415 Volts / 50 Hz
	Cap Feeding Bowl	300 Watt.
Height of Conveyor		860 mm to 910 mm

Depends on bottle size, cap size and type of cap.
We can supply as per customer requirements.
With help of change parts

Salient Features :

No container no cap arrangement.
Single motor synchronizes conveyor, star wheel, & platform turret.
Adjustable height of conveyor belt.
All contact parts are made out of stainless steel.
Pick & Place arrangement.
Torque adjustable
Low noise level, low power consumptions.

Robust and Hygienic Construction

Constructed with premium stainless steel, this screw cap sealing machine guarantees both longevity and easy sanitation. Its corrosion-resistant nature ensures it withstands rigorous industrial environments, adhering to high standards in food, beverage, and pharma sectors.

Advanced Automation and Control

Equipped with Human Machine Interface and PLC control technology, the machine offers seamless operation and monitoring. These advanced controls not only boost productivity but also minimize error rates, delivering consistent capping performance every cycle.

Eco-Friendly and Energy Efficient

Designed with an eco-friendly approach, the machine optimizes energy consumption and supports electrical voltages from 110 to 215V. Its intelligent system ensures efficient operation while helping organizations meet sustainability targets.

FAQs of Screw Cap Sealing Machine -Screw capper:

Q: How does the Screw Cap Sealing Machine operate?

A: This machine functions automatically using an electric drive and PLC control system. Operators can manage settings and monitor the process via the Human Machine Interface, allowing seamless and consistent screw cap application on bottles.

Q: What is the benefit of using a multi-head screw capper in production?

A: A multi-head configuration enhances productivity by allowing simultaneous capping of multiple bottles, significantly increasing throughput and reducing production time for industrial applications.

Q: Where can this screw cap sealing machine be installed and used?

A: It is suitable for installation in industrial facilities like bottling plants, pharmaceuticals, and cosmetic production lines across India. Its design supports integration with existing automated production systems.

Q: When is routine maintenance recommended for this machine?

A: Routine maintenance is typically advised every six months to ensure optimal performance. Regular checks on moving parts, electrical systems, and cleaning of the stainless steel surfaces are recommended.

Q: What control features does the machine offer for users?

A: It provides PLC-based control complemented by a Human Machine Interface, empowering operators with real-time monitoring, process adjustments, and rapid troubleshooting capabilities.

Q: How does using this machine contribute to eco-friendly manufacturing?

A: Its energy-efficient electric drive and optimized operation reduce power consumption while the stainless steel construction facilitates easy cleaning, contributing to resource conservation and cleaner production environments.
