Configuration:
According to the characteristics of the trapping label machine, we make improvement from the aspects of mechanical structure, circuit design, and intellectual control to improve the production efficiency. It can satisfy the demands of various beverage manufacturers as well as reduce the production cost for the clients and improve the production rate.
H-type design of the mechanism ensures the requirements of four-wheel drive, automatic centering and four-wheel balanced pressure. Because of the design of the equal velocity ratio, it completely realizes the goals of accurate casing label, smooth label transmission, stable operation and swift label cutting.
Applicable Varieties for Trapping Label:
With a breakthrough of the traditional technology of casting label, the equipment can integrate three to four trapping label machine varieties into one. It only needs to change the modules to realize the casting label of different varieties & types
It is added with the motor encoder for servo motor conveying line with high disposition, whole line automatic stemless speed adjustment.
Input Power | 2.0KW |
Input Voltage | three-phase,380/220VAC |
Production Efficiency | 300-350Bottles/min |
Size of Host Machine | 2500L*1200W*2200H |
Applicable Diameter of Bottle Body | ?28 mm-?125mm |
Applicable Length of Label | 30 mm ~ 180mm |
Applicable Thickness of Label | 0.03 mm ~0.13 mm |
Applicable Internal Diameter of Paper Tube | 5~10 adjust it at will |
