Automatic Six Head ROPP Cap Sealing Machine

Price 1350000 INR/ Unit

Get a Price/Quote

MOQ : 1 Piece

Automatic Six Head ROPP Cap Sealing Machine Specification

Product Type
Ropp Cap Sealing Machine

General Use
Industrial

Material
Stainless Steel Alloy

Computerized
No

Automatic
Yes

Voltage
220-415 Volt (v)

Feature
ECO Friendly

Color
Silver

Warranty
1 year

Automatic Six Head ROPP Cap Sealing Machine Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
30 Pieces Per Month

Delivery Time
4-6 Week

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
wooden packing

Main Domestic Market
All India

Certifications
CE & ISO Certified

About Automatic Six Head ROPP Cap Sealing Machine

Six Head Ropp Cap Sealing Machine (For Bottles) SBCS-200R

SBCS-200R Automatic Six Head ROPP Cap Sealing Machine is a compact model used for sealing of ROPP Caps on the bottle.

Operation :

Previously filled bottles with Dry syrup powder or liquid syrup are continuously fed from filling machine to the flat conveyor belt of sealing machine and move further through infeed worm for correct spacing between two bottles and transferred to the infeed star wheel. ROPP caps kept in orientation unit automatically orient caps in right direction before entering into delivery chute. And Bottle is entering below the sealing head, consist of total four rollers. Two rollers properly Skirts, Spins and Seals the cap and and simultaneously another two roller performs perfect threading according to bottle neck diameter. After sealing operation, sealing head moves upward with the help of cam and bottle move with exit starwheel and move further on conveyor belt for next operation.

Salient Features :

Parts coming in contact with the bottle or the Aluminum cap or exposed to the atmosphere are made out of stainless steel or duly powder coated for good house keeping and good manufacturing practice.
Single motor synchronies conveyor, starwheels and sealing head. The speed can be varied by the % speed pot on operating pane.
A special clutch device is incorporated on the Starwheel system for stoppage of machine in the event, bottle is turned or over diameter.
A photo sensing device stops machine automatically in the event, there is no ROPP cap in delivery chute.
Sealing pressure can be varied to suit different gauges and sizes of ROPP caps.
Damaged cap quantity be reduced by adjusting the gap between upper and lower plate of orientation unit

Basic Machine :

Imported Gear Motor for Main drive Imported Gear box for orientation unit
A.C. Frequency drive for Mai9n drive
Digital counter for counting number of sealed bottles
"No Seal in Chute, Machine Stops System"
Acrylic cabinet with Aluminium Structure for Machine.

Technical Details :

Model	SBCS-200R
Direction	Left to Right
Production Rate	Upto 60 to 150 bottles/min.
Electrical Supply	1.00 HP for Main Drive 0.25 HP for Orientation unit
No. of Sealing Head	Six heads
Power Requirement	440 Volts, 3 Phase (4 wire system) 50 Hz.
Height of Conveyor	Adjustable from 800 to 850 mm
Dimensions	1830 mm (L) x 961 mm (W) x 2130 mm (H)
Net weight	650 Kgs. (Approx.)
Gross Weight	800 Kgs. (Approx.)

Bottle Diameter	22 to 60 mm Maximum.
Height	55 mm to 110 mm Maximum.
ROPP Caps	22, 25, 28 & 32 mm Diameter (with the help of change parts.)

Note:

(1)Right of technical improvements & modifications reserved

(2) All illustrations and dimensions are shown for information only

Efficient Cap Sealing Performance

Our Automatic Six Head ROPP Cap Sealing Machine delivers precision and speed, handling up to 80 bottles per minute. With its electric drive and automatic grade, users can achieve consistent and secure sealing for a wide range of bottle types in industrial applications, boosting productivity and reducing labor dependence.

Advanced Control System and Versatility

Equipped with frequency speed control, the machine offers flexible operation tailored to your specific requirements. The control system ensures precision and adaptability during processing, while the voltage range (220-415V) can be configured to suit the operational environment, resulting in seamless integration within existing production lines.

Durability and Warranty Assurance

Built from high-grade stainless steel alloy, the machine is durable and resistant to industrial wear. A 12-month warranty against manufacturing defects provides peace of mind to buyers, though this does not include electronic parts such as motors or PLCs. This assurance supports reliability and after-sales satisfaction.

FAQs of Automatic Six Head ROPP Cap Sealing Machine:

Q: How does the frequency speed control benefit the cap sealing process?

A: The frequency speed control allows operators to adjust the sealing speed according to production needs. This flexibility helps maintain consistent output without compromising sealing quality, enhancing process efficiency.

Q: What is the process for setting up the Automatic Six Head ROPP Cap Sealing Machine in an industrial environment?

A: Setup involves positioning the machine, connecting it to the required electric power source (220-415V as specified by the customer), and configuring the control system. Trained personnel should handle the initial installation and configuration to ensure optimal performance.

Q: When does the warranty period begin for this machine?

A: The warranty begins from the date of dispatch and lasts for 12 months. It covers manufacturing defects and issues relating to workmanship, but excludes electronic components such as motors and sensors.

Q: Where is the machine most commonly used?

A: This cap sealing machine is used in industrial bottling operations, including pharmaceuticals, food and beverage, and chemical packaging plants, predominantly by distributors, exporters, manufacturers, and suppliers in India.

Q: What are the advantages of the machines stainless steel alloy construction?

A: Stainless steel alloy ensures long-term resistance to corrosion, structural integrity, and compatibility with hygienic processing environments, making it suitable for demanding industrial operations.

Q: Can the machines voltage be customized for different regions?

A: Yes, the machines voltage requirements can be tailored according to the customers specifications, ensuring compatibility with various regional electrical standards.
