FILLING SYSTEM:-
The filling system fills every bottle to the desired volume adopting the Vent pipe filling principle for accurate filling.The mechanical spring loaded filling valves are actuated automatically by the bottles when lifted up to commence filling. In this stage again the bottles are held at the neck by neck holding lifters. The machine operating speed can be varied using variable speed AC drive.
CAPPING SYSTEM:-
In capping system the bottles held at the neck firmly during capping to produce absolutely leak proof results. Caps are feed into the machine by an automatic cap elevator with an SS304 ground level hopper which can accommodate up to two thousand caps. The cap elevator feed caps at the desired rates to the cap pickup rotor of the machine.
TECHNICAL DETAILS
Machine dimensions :- | 8 Feet X 8 Feet without in feed & out feed conveyor |
With Out feed Conveyor :- 40 feet Length | |
Main Motor :- | 2 H.P. With Variable Speed-3 Phase |
Washing Pump :- | 1 H.P. |
Cap Elevator Motor Gear Motor :- | H.P. 3Phase |
Air Conveyor Blower Motor :- | H.P. 2 Nos. Phase |
Out feed Conveyor Motor :- | H.P. 3 Phase |
Shrink Tunnel Blower Motor :- | H.P. 3 Phase |
Out Feed Conveyor(S.S. Slate Conveyor) :- | 5 Meter |
Air Conveyor :- | 3 Meter |
Automatic Lubricating System At Necessary Parts | (Connected load:-5 hp three phase) |
Filling Volume:- | 100 ml to 1000 ml |
Maximum diameter of bottles :- | 95m.m. |
Maximum height of bottles :- | 335m.m |
